Super Narrow Bezel, 2.3mm (U/L)+1.2mm (R/B) Available
Thin & Light Body (Compared with DLP Rear Projection Cube)
Industrial-grade Screen Lead to Stable Performance
178°(H/V) Wide Viewing Angle
Intelligent Color and Brightness Adjustment
LED Backlight, Low Power Consumption
High Speed Response
FHD Display, High Contrast Ratio, High Brightness
|
Screen |
Screen Size |
46" |
|
Panel Type |
S-PVA (DID) |
|
|
Driver Element |
a-Si TFT active matrix |
|
|
Image Area |
1018.08×572.67mm |
|
|
Pixel Pitch |
H/V: 0.53025mm |
|
|
Viewing Angle |
178°(H)/178°(V) |
|
|
Backlight Source |
Direct LED Backlight |
|
|
Luminance of White |
700cd/㎡ (Typ) |
|
|
Contrast Ratio |
3500:1 |
|
|
Response Time |
8ms |
|
|
Physical Resolution |
1920×1080(FULL HD) |
|
|
Display Colors |
16.7M (8bit) |
|
|
Bezel Width |
2.3mm(U/L), 1.2mm(R/B) |
|
|
Operating Life Time |
50,000 hrs |
|
|
Interface |
Signal Input |
Solution1: VGA, DVI, HDMI, CVBS Solution 2: VGA, DVI, HDMI, CVBS, RJ45 (Signal Loop) |
|
Signal Output |
Solution 1: CVBS (Signal Loop) Solution 2: RJ45 (Signal Loop) |
|
|
Control Input |
Solution 1: RS232 IN (RJ45), DEBUG ISP (RJ45), IR IN (Remote) Solution 2: RS232 IN, RJ45 IN, USB, IR IN (Remote) |
|
|
Control Output |
Solution 1: RS232 OUT*2 (RJ45) Solution 2: RJ45*1 |
|
|
Working Conditions |
Power Consumption |
160W |
|
Power Supply |
AC 100-240V,50/60Hz |
|
|
Operating Temperature |
0-50℃ |
|
|
Operating Humidity |
20-90% (Non-condensing) |
